型号 |
软管规格 |
螺纹尺寸公制 |
AG外径(mm) |
AG内径(mm) |
GL(mm) |
H |
包装单位个/包 |
|
LNE-*-F-M12 |
AD10.0 |
M12×1.5 |
12 |
8 |
8 |
19 |
100 |
|
LNE-*-F-M12 |
AD13.0 |
M12×1.5 |
12 |
8 |
8 |
19 |
100 |
|
LNE-*-F-M16 |
AD13.0 |
M16×1.5 |
16 |
10 |
10 |
20 |
100 |
|
LNE-*-F-M18 |
AD13.0 |
M18×1.5 |
18 |
13 |
10 |
20 |
100 |
|
LNE-*-F-M16 |
AD15.8 |
M16×1.5 |
16 |
10 |
10 |
20 |
100 |
|
LNE-*-F-M18 |
AD15.8 |
M18×1.5 |
18 |
13 |
10 |
20 |
100 |
|
LNE-*-F-M20 |
AD15.8 |
M20×1.5 |
20 |
16 |
10 |
20 |
100 |
|
LNE-*-F-M20 |
AD18.5 |
M20×1.5 |
20 |
16 |
10 |
20 |
50 |
|
LNE-*-F-M20 |
AD21.2 |
M20×1.5 |
20 |
16 |
10 |
20 |
50 |
|
LNE-*-F-M24 |
AD21.2 |
M24×1.5 |
24 |
20 |
10 |
20 |
50 |
|
LNE-*-F-M25 |
AD21.2 |
M25×1.5 |
25 |
21 |
15 |
25 |
50 |
|
LNE-*-F-M25 |
AD25.0 |
M25×1.5 |
25 |
21 |
15 |
25 |
50 |
|
LNE-*-F-M25 |
AD28.5 |
M25×1.5 |
25 |
21 |
15 |
25 |
50 |
|
LNE-*-F-M27 |
AD28.5 |
M27×2.0 |
27 |
21 |
15 |
25 |
50 |
|
LNE-*--M30 |
AD28.5 |
M30×2.0 |
30 |
21 |
15 |
25 |
50 |
|
LNE-*-F-M32 |
AD28.5 |
M32×1.5 |
32 |
26 |
15 |
30 |
50 |
|
LNE-*-F-M32 |
AD34.5 |
M32×1.5 |
32 |
26 |
15 |
30 |
20 |
|
LNE-*-F-M36 |
AD34.5 |
M36×2.0 |
36 |
28 |
15 |
32 |
20 |
|
LNE-*-F-M40 |
AD34.5 |
M40×1.5 |
40 |
35 |
15 |
40 |
20 |
|
LNE-*-F-M40 |
AD42.5 |
M40×1.5 |
40 |
35 |
15 |
40 |
10 |
|
LNE-*-F-M48 |
AD42.5 |
M48×2.0 |
48 |
38 |
15 |
40 |
10 |
|
LNE-*-F-M50 |
AD54.5 |
M50×1.5 |
50 |
44 |
18 |
42 |
10 |
|
LNE-*-F-M60 |
AD54.5 |
M60×2.0 |
60 |
55 |
18 |
42 |
10 |
|
型号 |
软管规格 |
螺纹尺寸公制 |
AG外径(mm) |
AG内径(mm) |
GL(mm) |
H |
包装单位个/包 |
|
LNE-*-G-PG7 |
AD10.0 |
PG7 |
12.5 |
8.5 |
8 |
20 |
100 |
|
LNE-*-G-PG9 |
AD13.0 |
PG9 |
15.2 |
11 |
8 |
20 |
100 |
|
LNE-*-G-PG11 |
AD15.8 |
PG11 |
18.6 |
14 |
10 |
20 |
100 |
|
LNE-*-G-PG13.5 |
AD15.8 |
PG13.5 |
20.4 |
16 |
10 |
20 |
100 |
|
LNE-*-G-PG13.5 |
AD18.5 |
PG13.5 |
20.4 |
16 |
10 |
20 |
50 |
|
LNE-*-G-PG16 |
AD21.2 |
PG16 |
22.5 |
17 |
10 |
20 |
50 |
|
LNE-*-G-PG21 |
AD28.5 |
PG21 |
28.3 |
23 |
14 |
25 |
50 |
|
LNE-*-G-PG29 |
AD34.5 |
PG29 |
37 |
31 |
14 |
35 |
20 |
|
LNE-*-G-PG36 |
AD42.5 |
PG36 |
47 |
40 |
15 |
40 |
10 |
|
LNE-*-G-PG48 |
AD54.5 |
PG48 |
59.3 |
51 |
20 |
44 |
10 |
|
型号 |
软管规格 |
螺纹尺寸公制 |
AG外径(mm) |
AG内径(mm) |
GL(mm) |
H |
包装单位个/包 |
|
LNE-*-G1/2 |
AD21.2 |
G1/2 |
20.4 |
15 |
10 |
25 |
50 |
|
LNE-*-G3/4 |
AD28.5 |
G3/4 |
26 |
21 |
15 |
25 |
50 |
|
LNE-*-G1″ |
AD34.5 |
G1″ |
33 |
26 |
15 |
30 |
20 |
详情请致电 18357361157 屠方强
